Camera |
Sensor type |
CMOS, rolling shutter |
|
Sensor |
IMX178 |
|
Pixel size |
2.4 μm × 2.4 μm |
|
Sensor size |
1/1.8" |
|
Resolution |
3072 × 2048 |
|
Max. Frame Rate |
30.7 fps |
|
Dynamic range |
71.3 dB |
|
SNR |
41.3 dB |
|
Gain |
0 dB to 24 dB |
|
Exposure time |
25 μs to 2.5 sec |
|
Exposure mode |
Off/Once/Continuous exposure mode |
|
Mono/Color |
Mono |
|
Pixel format |
Mono 8/10/10p/12/12p |
|
Binning |
Supports 1 × 1, 2 × 2 |
|
Decimation |
Supports 1 × 1, 2 × 2, 4 × 4 |
|
Reverse image |
Supports horizontal and vertical reverse image output |
|
Electrical features |
Data Interface |
GigE |
|
Digital I/O |
6-pin Hirose connector provides power and I/O, including opto-isolated input × 1 (Line 0), optoisolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2). |
|
Power supply |
9 VDC to 24 VDC, supports PoE |
|
Power consumption |
Typ. 2.4 W@12 VDC |
|
Mechanical |
Lens mount |
C-Mount |
|
Dimension |
29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.2") |
|
Weight |
Approx. 100 g (0.22 lb.) |
|
Ingress protection |
IP40 (under proper lens installation and wiring) |
|
Temperature |
Working temperature: -30 °C to 60 °C (-22 °F to 140 °F)
Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F) |
|
Humidity |
20% to 95% RH, non-condensing |
|
General |
Client software |
MVS or third-party software meeting with GigE Vision Protocol |
|
Operating system |
32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS |
|
Compatibility |
GigE Vision V2.0, GenICam |
|
Certification |
CE, FCC, RoHS, KC |
|
EMVA Data(typical) |
Quantum Efficiency |
83.8% |
|
Dark Noise |
2.8 e- |
|
Signal-to-Noise Ratio |
41.2 dB |
|
Saturation Capacity |
13.9 ke- |
|
Dynamic Range |
71.5 dB |
