Key Feature
Adopts 12 MP sensor to provide high-quality images.
Flexible installation and convenient debugging.
Supports continuous reading of various codes without stopping.
Supports recognizing various poor printing quality codes.
Supports networking of multiple devices.
Ingress protection 67.
Available Model: MV-ID6120PM-00C-NNG
Dimension
*The data herein may vary based on the environment, objects and other various factors, and HIKROBOT shall not assume the consequences arising therefrom.
Model
Model
MV-ID6120PM-00C-NNG
Type
12 MP Smart Code Reader
Performance
symbologies
1-dimensional codes: Code 39, Code 128, Code 93, ITF 25, CodaBar, EAN
2-dimensional codes: QR, Data Matrix
Max. frame rate
28 fps
Max. reading speed
84 codes/sec
Sensor type
CMOS, global shutter
Pixel size
3.2 µm x 3.2 µm
Sensor size
1"
Resolution
4096 × 3072
Exposure time
16 μs to 1 sec
Gain
0 dB to 40 dB
Mono/color
Mono
Communication protocol
SmartSDK, TCP Client, TCP Server, Serial, FTP, HTTP
Electrical features
Data interface
GigE
Digital IO
12-pin M12 connector provides power and I/O, including opto-isolated input (LineIn 0/1/2) × 3, opto-isolated output (LineOut 0/1/2) × 3, RS-232 input × 1, and RS-232 output × 1
Power supply
12 VDC to 24 VDC
Max. power consumption
12 W@24 VDC
Mechanical
Lens mount
C-mount
Light source
Not included
Lens cap
Included
Dimension
126 mm × 66 mm ×113.2 mm (5.0" × 2.6" × 4.5")
Weight
Approx. 750 g (1.7 lb.)
Ingress protection
IP67 (under proper installation of lens waterproof cap)
Temperature
Working temperature: 0 °C to 50 °C (32 °F to 122 °F)
Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
Humidity
20% to 95% RH, without condensation
General
Client software
IDMVS
Certification
CE, FCC, RoHS
