Key Feature
Ultra high resolution and consistency of image clarity
Bigger aperture, lower distortion and higher relative illumination rate
Achromatic optical system design, Better imaging performance with color camera
Excellent vibration resistance performance, optical axis shifting within pixel level
Good stability at high and low temperature
Multilayer and broadband coating design, compatible with visible and near-infrared applications
Available Model: MVL-HF1224M-10MP
Dimension
*The data herein may vary based on the environment, objects and other various factors, and HIKROBOT shall not assume the consequences arising therefrom.
Model
Model
MVL-HF1224M-10MP
Type
1/1.8” 12mm 10MP FA LENS
Performance
Focal Length
12 mm
F-Number
F2.4 ~ F16
Image Size
Φ9 mm(1/1.8'')
Distortion
0.15%
Minimum Operation Distance
0.1 m
Field of View
D(8.96mm):40.2°
H(7.38mm):33.6°
V(4.92mm):22.9°
Mechanical
Iris Control
Manual
Focus Control
Manual
Filter Thread
M27×0.5
Mount
C-Mount
Flange Back Length
17.526 mm
Dimension
Φ29×37 mm
Weight
65.9 g
Temperature
-10 ~ 50℃
General
Certification
RoHS2.0
